Wall Plaster Machine Price with 6Million m2 Capacity

How is the gypsum powder produced? The crusher breaks the large-size gypsum ore into small portions of 25 mm, and then sends the small portions to the grinder. After grinding, the certified gypsum powder is despatched to the boiling furnace for calcination, and the unqualified phase is despatched to the grinder till qualified. After calcination, the certified gypsum powder is despatched to the screw conveyor thru the elevator.

The screw conveyor sends the calcined gypsum powder to the silo for storage, and in the process, the gypsum powder is cooled. The dirt collector is positioned at the pinnacle of the silo, and the unqualified section is despatched to the grinder till it is qualified
The saved gypsum will be despatched to the product warehouse via the metal impeller feeder, screw conveyor, elevator, and the remaining certified gypsum powder will be despatched to the warehouse or workshop. The pinnacle pulse bag dirt collector will acquire dirt from the crusher, pellet bin. When dirt and dirt fuel enter the dirt collector thru the inlet, massive measurement dirt particles will fall due to the make bigger in dimension and the minimize in wind speed. Small dirt particles will be filtered thru a filter bag. The filtered gasoline will be discharged thru the outlet.
